DESCRIPTION

Basic Info.

Material	Forged Steel
Connection Form	Thread
Structure	Swing
Pressure	Ordinary Pressure
Function	Ddcv Double Lobe
Sealing Form	Seat Ring
Flow Direction	Unidirection
Standard	ANSI
Application	Industrial Usage
Product Name	Check Valve
Materials	A105, Lf2, F5, F11, F22, F304, F316, F304L,etc. an
Pressure Rating	ASME 150#,300#,600#,900#,1500#, 2500#
End Connection	Flanged RF, FF, Rtj, Bw
Design	BS 1868 / API 6D / ASME B16.34
Face to Face	ASME B16.10
End Flange	ASME B16.5
Bw End	ASME B16.25
Test	API598
Transport Package	Plywood Case
Specification	DN15 up to DN50
Trademark	BVC
Origin	China
HS Code	8481804090

Product Description

Company Introduction

BONNY VALVE manufactures a wide range of valve products including Ball,Gate,Globe,Check and Butterfly Valves for Oil,Gas&Petrochemical industries,marine,energy,water and waste among others.

Consistent product quality and best prices make BONNY VALVE a dependable choice for cast and forged valves in carbon, stainless and alloy steel materials.
BODY MATERIALS:
ALLOY STEEL:ASTM A217 WC1,WC6,WC9,C5,C12.A182 F11,F22,F5,F91......
STAINLESS STEEL:ASTM A351 CF8M, CF3M, CF8, CF8C.A182 F304,F316,F321,F347,F51,F53......

CARBON STEEL:ASTM A216 WCB, A105N,A352 LCB/LCC,A350 LF2.

BONNY VALVE maintains an extensive quality system, which complies with the requirements of major oil companies, industry standards and to ISO 9001:2015 &2014/68/EU PED CE standard.

We sell to OEM's, contractors, end-users and other distributors.
If you have a valve requirement, please give us the opportunity to assist you.

Certificates

Packing&Delivery

FAQ

Q: Are you trading company or manufacturer ?
A: We are factory,Located in Wenzhou,China.

Q: How long is your delivery time?A: Generally it is 3-5 days if having stocks. or 30-45 days according to your quantity.Q: We are interested in your products?A: In order to recommend you suitable products, please provide detail information, like size, material, pressure, model.Q: Can you produce according to our own drawings?A: Yes,we can produce according to your design,draing or just an ideaQ: What is your terms of payment ?A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.Q:What is your Core Products? A: Our Main Producs are all kinds of valves,like gate valve,globe valve,check valve,ball valve,butterfly valve for for Oil,Gas&Petrochemical industries,marine,energy,water and waste among others.Q:What's Warranty of your product? A: The warranty time is 18 months after leaving our factory. We can repair or change because of the quality problems.

Product Information

FORGED SWING/PISTON TYPE - BOLTED / WELDED / PRESSURE SEAL BONNET

Bonny Valve has very extended experience in manufacturing of Forged Swing/Piston Type Check Valves,including ¼"-2", ANSI 150#-1500#. Materials of construction include Carbon Steel, Stainless Steel, Alloy 20, and other exotic materials.

Size: ½" up to 2"(DN15 up to DN50)

Pressure Rating: ASME 150# to 2500#

Materials: Forged Carbon Steel, Low Temperature Carbon Steel, Stainless Steel, Duplex Stainless Steel, Super Duplex Stainless Steel, Nickel Alloys, Nickel Aluminum Bronze, Hastelloy, Inconel Etc.

End Connection: Flanged RF, FF, RTJ, BW, NPT, SW Ends

Specification:

• Design - API602 / BS5352 / ASME B16.34
• End Flange - ASME B16.5
• BW End - ASME B16.25
• SW End - ASME B16.11
• Screwed Ends - ASME B1.20.1
• Test - API598
• Special - NACE MR-01-75

Features:

• Bolted Cover , Welded Bonnet or Pressure Seal Bonnet
• Full port or Conventional Port
• Swing or Piston Disc

Product parameters

1. Design	API602, ANSI B16.34, BS5352, GB/T12224, GB/T12228, GB/T12234
2. Socket Welding End	ANSI B16.11, JB/T175-95
3. Screw End	ANSI B1.20.1(NPT), GB/T7306-87(RC)
4. Butt Welding End	ANSI B16.25, GB/T12224
5. Flange End	ANSI B16.5, JB/T82.1"82.4-49
6. Face to Face of Flaned Valves	ANSI B16.10.JB/T97-95
7. Construction	Bolted Bonnet(BB)/Welded Bonnet(WB)
8. Inspect & Test	API598, GB/T13927, JB/T9092
9. Body Materials	A105, LF2, F5, F11, F22, F304, F316, F316L,etc. and Monel, Alloy20

• Our quality control is approved by ISO 9001&2014/68/EU PED CE.
  Now we have lots of CS and SS valves in stock to ensure good price and fast delivery.

•











Packing Details:	Inner Package:bubble bags + plastic cover Outer Package:plywoodcase
Delivery Details:	Generally it is 5-10 days if the goods are in stock. Or 30~45 days after receiving the payment.
